Bogie |
|||||||||||||||||
|
High Mounting Series |
|||||||||||||||||
|
Model |
Capacity |
Track |
Height |
Wheel base |
brake |
bearing |
Leaf Spring Center Distance |
Brake Chamber Distance |
High Mounting Platform Area |
Stud |
P.C.D |
Tyre |
Wheel |
Spacer |
Leaf Spring |
Total Length |
Weight |
|
WK2401H |
2×12 |
1840 |
660 |
1500 |
S420×180 |
33118 33213 |
980 |
393 |
700×1060 |
6-M20×2 |
|
12.00R24 |
8.5-24 |
130-24 |
90/18 |
2150 |
≈2088 |
|
WK2411H |
2×12 |
1840 |
660 |
1400 |
S420×180 |
33118 33213 |
980 |
421 |
700×1060 |
10-M22×1.5 |
335/281 |
12.00R20 |
7.50V-20 |
|
90/18 |
2160 |
≈1942 |
|
WK2411H1 |
2×12 |
1850 |
660 |
1400 |
S420×180 |
33118 33213 |
980 |
421 |
700×1060 |
10-M22×1.5 |
335/281 |
12.00R20 |
7.50V-20 |
|
90/18 |
2160 |
≈1942 |
|
WK2801H |
2×14 |
1840 |
660 |
1550 |
S420×200 |
32219 33215 |
900 |
245 |
800×980 |
6-M20×2 |
|
12.00R24 |
8.50V-20 |
Ø382 |
120/17 |
2235 |
≈2490 |
|
WK2811H |
2×14 |
1840 |
660 |
1550 |
S420×200 |
32219 33215 |
900 |
245 |
800×980 |
10-M22×1.5 |
335/281 |
12.00R20 |
8.50V-20 |
|
120/17 |
2190 |
≈2406 |
|
WK2811H1 |
2×14 |
1850 |
660 |
1550 |
S420×200 |
32219 33215 |
900 |
245 |
800×980 |
10-M22×1.5 |
335/281 |
12.00R20 |
8.50V-20 |
|
120/17 |
2190 |
≈2406 |
|
WK3201H |
2×16 |
1840 |
660 |
1550 |
S420×200 |
32222 32314 |
900 |
243 |
800×980 |
6-M20×2 |
|
12.00R24 |
8.5-24 |
147-24 |
120/17 |
2250 |
≈2646 |
|
WK3211H |
2×16 |
1840 |
660 |
1550 |
S420×200 |
32222 32314 |
900 |
243 |
800×980 |
10-M22×1.5 |
335/281 |
12.00R20 |
8.50V-20 |
|
120/17 |
2250 |
≈2490 |
|
WK3211H1 |
2×16 |
1850 |
660 |
1550 |
S420×200 |
32222 32314 |
900 |
243 |
800×980 |
10-M22×1.5 |
335/281 |
12.00R20 |
8.50V-20 |
|
120/17 |
2250 |
≈2490 |
|
WK3601H |
2×18 |
1840 |
660 |
1550 |
S420×220 |
32222 32314 |
900 |
243 |
800×980 |
6-M20×2 |
|
12.00R24 |
8.5-24 |
147-24 |
120/17 |
2250 |
≈2674 |
|
WK3611H |
2×18 |
1840 |
660 |
1550 |
S420×220 |
32222 32314 |
900 |
262 |
800×980 |
10-M22×1.5 |
335/281 |
12.00R20 |
8.50V-20 |
|
120/17 |
2250 |
≈2512 |
|
WK3611H1 |
2×18 |
1850 |
660 |
1550 |
S420×220 |
32222 32314 |
900 |
262 |
800×980 |
10-M22×1.5 |
335/281 |
12.00R20 |
8.50V-20 |
|
120/17 |
2250 |
≈2512 |
